Mic Wiring

Stock
1- Shield
2- Receive
3- Transmit
4- Audio

Astatic (4 wire)
1- Shield
2- Black
3- Red
4- White

Astatic (6 wire)
1- Shield & Blue
2- Black
3- Red
4- White
Yellow NC

Daiwa EM-500
Cobra CA Series
1- Shield & Black
2- Blue
3- White
4- Red

Galaxy DC-521S (4 wire)
1- Shield
2- Black
3- Red
4- Yellow

Galaxy CB-660EI
1- Shield & Black
2- Blue
3- Red
4- White

Sadelta
1- Shield
2- Green
3- Brown
4- White

Turner
1- Shield & Red
2- Black
3- Blue
4- White
Yellow NC
