Yaesu FT-891 and ATAS-120A in a Hybrid!

Discussion in 'Product Reviews' started by 2RT307, Jun 24, 2017.

  1. 2RT307

    2RT307
    Expand Collapse
    Sr. Member

    Joined:
    Nov 22, 2011
    Messages:
    2,148
    Likes Received:
    631
    Hi folks, I finally got around to installing the FT-891 and ATAS 120A in a 2015 Toyota Camry Hybrid. Everything on the internet says this is a waste of time, that Hybrids have way too much electronics and generate a ton of RFI. I decided to do it anyway to see for myself. (Honestly, plan B was to install it in my F-150 if it didn't work). This thing has a beast of a battery and charging system, which sits right behind the back seat.
    20170623_095138_zpsaj29dgyr
    A neat thing about the Camry Hybrid is the 12 volt battery sits in the trunk on the side. So, easy to run power to the rig, which we mounted under the front passenger seat.
    20170623_164610_zpsiyipwtzk
    Grounding is absolutely critical with this antenna, and probably even more so in a hybrid.
    20170623_104532_zpsoatgwemh


    We removed the sealant material and placed the metal plate in it's place, then connected one ground strap to the mount to ensure we had a good ground. We did the other custom one just in case this one didn't give us enough, and buttoned it all up.
    20170623_112243_zpsk4vvghil

    I got the mount and ground strap at R+L Electronics. It's a Comet HD-5. I liked it better than the Diamond model due to a short section of RG-188A that transitions to heavier RG-58 for the rest of the run. It also allows you to remove the PL-259 end in case you run it through a very tight spot like a grommet.
    20170623_112026_zpsfs1saq9q

    Tommy made a custom cup mount for the remote head out of PVC pipe, wrapped in a tough foam, and made a cap to go on top. We mounted the remote bracket to the top, and stuck it in the cup holder in the console.



    And guess what? You can't move the shifter into gear if it's in the first holder, so I moved it to the second, and we finished it off with some black dye, and angled it for easy viewing from the driver's seat. It is easily removable when I am in a less than secure area.
    20170624_100246_zpsoec2wdh2
    Finally, trying it out... not much RFI noise at all, except when braking, which is what I expected. I mostly travel on the highway for long trips (this is my work car). I have made several other contacts here in the U.S. since we installed it... so far, so good. The ATAS does what it's supposed to do, and I'm getting very good reports on the audio from the rig (I set the parametric eq settings in the radio). Haven't been on the air much, and forgot my vanity call, so I goofed this QSO! Loving the rig and antenna setup so far, and will give updates as I use it more.

    73,
    Brett


    #1 2RT307, Jun 24, 2017
    Last edited: Sep 14, 2017
    Riverman71 likes this.

  2. RatsoW8

    RatsoW8
    Expand Collapse
    Supporting Member, W9WDX ARC Member - WD8T

    Joined:
    Nov 3, 2009
    Messages:
    3,102
    Likes Received:
    1,340
    Nice. That's the same trunk lip mount and ground strap config I used on my Monte Carlo. I'll see if I can find the pic.

    2RT307 likes this.
  3. w9cll

    w9cll
    Expand Collapse
    W9WDX Amateur Radio Club Member

    Joined:
    Jan 19, 2013
    Messages:
    2,831
    Likes Received:
    1,439
    Nice setup! Mobile HF is a lot of fun

    2RT307 likes this.
  4. undertaker

    undertaker
    Expand Collapse
    Undertaker

    Joined:
    Apr 5, 2006
    Messages:
    1,490
    Likes Received:
    337
    Hey Brett neat set up im in San angelo!!!

    2RT307 likes this.
  5. undertaker

    undertaker
    Expand Collapse
    Undertaker

    Joined:
    Apr 5, 2006
    Messages:
    1,490
    Likes Received:
    337
    That just gave me a great idea for my new truck to mount the radio!!(y)(y)(y)

    2RT307 likes this.
  6. 2RT307

    2RT307
    Expand Collapse
    Sr. Member

    Joined:
    Nov 22, 2011
    Messages:
    2,148
    Likes Received:
    631
    Cool! I travel to San Angelo once in a while to see a customer of mine. I'll have to look you up next time I'm out there.

    73,
    Brett

  7. undertaker

    undertaker
    Expand Collapse
    Undertaker

    Joined:
    Apr 5, 2006
    Messages:
    1,490
    Likes Received:
    337
    Please do!!!!

  8. 2RT307

    2RT307
    Expand Collapse
    Sr. Member

    Joined:
    Nov 22, 2011
    Messages:
    2,148
    Likes Received:
    631
    Well great... Photobucket.com no longer lets me post pics on web sites without paying 39 dollars a month. Any suggestions for alternative hosting sites?

  9. Tallman

    Tallman
    Expand Collapse
    W9WDX Amateur Radio Member, KW4YJ EXTRA class

    Joined:
    May 1, 2013
    Messages:
    1,643
    Likes Received:
    776
    Do you have an album on this site?

  10. 2RT307

    2RT307
    Expand Collapse
    Sr. Member

    Joined:
    Nov 22, 2011
    Messages:
    2,148
    Likes Received:
    631
    No sir. I can link from there if I set one up?

    73,
    Brett

  11. Tallman

    Tallman
    Expand Collapse
    W9WDX Amateur Radio Member, KW4YJ EXTRA class

    Joined:
    May 1, 2013
    Messages:
    1,643
    Likes Received:
    776
    Yes, that is where this picture is stored.
    [​IMG]
    Just go in to the DXGALLERY and setup an album.

    2RT307 likes this.
  12. 2RT307

    2RT307
    Expand Collapse
    Sr. Member

    Joined:
    Nov 22, 2011
    Messages:
    2,148
    Likes Received:
    631
    Cool, and thanks for the tip. I have a lot of pics that I have posted here via Photobucket over the years. But for this latest project, will open an album. Rig/Antenna combo works, but man, does the hybrid generate a lot of noise. I knew this going in... looking to use some chokes and more bonding to see if I can eliminate more of the RFI. Only using the Camry because it is a company car that I spend a lot of time in!

    73,
    Brett

  13. Tallman

    Tallman
    Expand Collapse
    W9WDX Amateur Radio Member, KW4YJ EXTRA class

    Joined:
    May 1, 2013
    Messages:
    1,643
    Likes Received:
    776
    I imagine that the Hybrid cars have lots of high frequency switching circuits on that Camry. Maybe they have some tips on making it quitter. If you start adding grounding straps, use brass braid. Brass is not very inductive.

  14. 2RT307

    2RT307
    Expand Collapse
    Sr. Member

    Joined:
    Nov 22, 2011
    Messages:
    2,148
    Likes Received:
    631
    Can anyone tell me if the pictures are working now? I think my computer is lying to me. lol

    73,
    Brett

  15. undertaker

    undertaker
    Expand Collapse
    Undertaker

    Joined:
    Apr 5, 2006
    Messages:
    1,490
    Likes Received:
    337
    Yes sir it is working............
